Paste/Ink for Glass Substrates

Transparent or translucent-compatible formulations that adhere to glass without compromising optical clarity. Common applications include heated display glass, invisible antenna lines on building windows, and automotive windshield defogging.

Main Products

ModelDescriptionSubstrateCuring ConditionSheet ResistanceFeatures & Application
CP600xConductive Silver PasteGlass600-650℃/3min≤ 3~7.5mΩ/sqAutomotive glass, architectural glass, etc
CP680xConductive Silver PasteGlass680-710℃/3min≤ 4~12mΩ/sqAutomotive glass, architectural glass, etc
CP6502Conductive Silver PasteMicrocrystalline glass, automotive glass, ITO glass, ultra white glass500℃/7~10min< 3mΩ/sq/milConductive circuits such as microcrystalline glass, automotive glass, ITO glass, and ultra white glass
CP7001Conductive Silver PasteMicrocrystalline glass, automotive glass, ITO glass, ultra white glass700℃/7~10min≤ 3mΩ/sq/milConductive circuits such as microcrystalline glass, automotive glass, ITO glass, and ultra white glass
CP5801Conductive Silver PasteMicrocrystalline glass, automotive glass, ITO glass, ultra white glass620℃/7~10min< 3mΩ/sq/milConductive circuits such as microcrystalline glass, automotive glass, ITO glass, and ultra white glass
RPG05Pd/Ag Resistor PasteGlass-ceramic850~900℃/10min20~100mΩ/sq600~2000ppm/℃, for glass-ceramic thick film heaters, with stable resistance, resistance to temperature shock
